SynaptoGreen™ C4 (Equivalent to FM®1-43)

A widely used green fluorescent dye for following synaptic activity by staining synaptic vesicles at the synapse or neuromuscular junctions. When used in combination with the red fluorescent dye SynaptoRed™ (70021), synapses or neuromuscular junctions can be imaged independently in two colours.

Name SKU Size Availability Vendor Price Order

SynaptoGreen™C4

 70020 1mg Generally 1-2 weeks from receipt of order Biotium Log in for pricing

SynaptoGreen™C4 5x1mg

 70022 5 x 1mg Generally 1-2 weeks from receipt of order Biotium Log in for pricing

Photos

Features

A widely used green fluorescent dye for following synaptic activity by staining synaptic vesicles at the synapse or neuromuscular junctions. When used in combination with the red fluorescent dye SynaptoRed™ (70021), synapses or neuromuscular junctions can be imaged independently in two colours. Research results from the Tsien and Kay labs showed that brain slices can be stained with SynaptoGreen™ when SR101 (Sulforhodamine 101, 80101) or ADVASEP-7 (70029) is used to reduce the background staining. Biotium offers several Nerve Terminal Staining Kits for staining brain slices. Also see AM1-43 (70024), which is similar to SynaptoGreen™, but with a formaldehyde-fixable amine group.

SynaptoGreen™ also can be used to stain bacteria (gram-positive or gram-negative) and yeast, although in yeast it rapidly internalizes to vacuolar membranes. See our Cellular Stains Table for more information on how our dyes stain various organisms.

  • λEx/λEm: 510/625 nm (in MeOH); 480/598 nm (in membranes)
  • Red solid soluble in water
  • C30H49Br2N3
  • MW: 612

Resources

Supporting Documents:
